19
DCM-390/290/27/500AE
PCM1732 (IC 107)
BA033FP (IC 02)
BA08T (IC 03)
74HCU04 (IC 103)
Serial
Input
I/F
Mode
Control
I/F
HDCD
Hidden
Code
Recovery
HDCD
8x
Oversampling
Digital Filter
Enhanced
Multi-Level
∆Σ
Modulator
Crystal/OSC
XTI
SCK
XTO CLKO V
CC1
AGND1 V
DD
DGND
HDCD
Amplitude
Decoding
V
OUT
L
V
CC2
L
V
CC2
R
AGND2R AGND2L
EXTL
PCM1732
Open
Drain
DAC
Low-Pass
Filter
Low-Pass
Filter
BPZ Control
V
OUT
R
EXTR
ZERO
DAC
ML/I
2
S
MC/DEM
MD/FSS
CS/IWO
MODE
MUTE
RST
LRCIN
DIN
BCKIN
Power Supply
Power-On Reset
