28
DCM-390/290/27/500AE
C307,308 - CHIP CAPACITOR (1500pF/50V)
413-DCM280-769
2
C312 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
1
C315 - CHIP CAPACITOR (39pF/50V)
413-390-987
1
C316 - CHIP CAPACITOR (0.1uF/50V)
413-DCM280-773
1
C317 - ELEC.CAPACITOR (100uF/10V)
413-HMA2200-5017
1
OTHER PARTS GROUP
CN03 nsp 00D 941 0047 104 5P SOCKET
404-SPPW3-513
1
CN04 nsp 00D 941 0047 201 3P SOCKET
404-KMD3500-609
1
CN101 00D 941 0047 308 16P FFC CONNECTOR
404-HV3423K-583
1
CN102 nsp 00D 958 0013 505 6P SOCKET
404-90V1-101
1
CN103 00D 941 0047 405 11P FFC CONNECTOR
404-300-1914
1*
CN104 nsp 00D 958 0041 506 7P SOCKET(S7B-PH-K,JST)
404-HMD5000-785
1
CN105 nsp 00D 941 0047 502 8P SOCKET
404-DV300-506
1
CN106 00D 941 0047 609 13P FFC CONNECTOR
404-385-2086
1*
CN107 00D 941 0047 706 30P FFC CONNECTOR
404-385-2088
1*
CN301 nsp 00D 941 0047 803 3P SOCKET
404-DJ100-1077
1
J04 - CHIP RESISTOR (0 OHM,1/8W)
412-DJ3000-414
1
J15 - CHIP RESISTOR (0 OHM,1/8W)
412-DJ3000-414
1
J26,27 - CHIP RESISTOR (0 OHM,1/8W)
412-DJ3000-414
2
J36 - CHIP RESISTOR (0 OHM,1/8W)
412-DJ3000-414
1
J88 - CHIP RESISTOR (0 OHM,1/8W)
412-DJ3000-414
1
J98 - CHIP RESISTOR (0 OHM,1/8W)
412-DJ3000-414
1
J105 - CHIP RESISTOR (0 OHM,1/8W)
412-DJ3000-414
1
JK101 00D 941 0047 900 2P RCA JACK (RJ-1060-10-0300A)
420-R1C-173A
1
JK102 00D 941 0048 006 SIGNAL JACK (D-SMB,205A09FGTBB3) for 390BKE3
420-MP3-104
1
JK103,104 00D 958 0074 706 HEADPHONE JACK (JY-3535-01-030G)
420-HMDV3360K-5014
2
JK106 00D 958 0074 609 1P RCA JACK (RJ-1081-31-0341A)
420-HDJ2650-097A
1
L101-106 00D 958 0016 900 BEAD CORE (86-019-A)
415-HV3500K-090
6
L109 00D 958 0016 900 BEAD CORE (86-019-A)
415-HV3500K-090
1
L110 00D 958 0016 900 BEAD CORE (86-019-A) for 390BKE3
415-HV3500K-090
1
L111 00D 958 0017 006 INDUCTOR (10uH)
415-MPG100-047
1
L112 00D 941 0048 103 BEAD (RH03506BT-B)
415-DMC370E3-134
1
L113 00D 958 0016 900 BEAD CORE (86-019-A)
415-HV3500K-090
1
L114 00D 941 0048 200 BEAD (RH03506BT-B)
415-DMC370E3-134
1
L115 00D 958 0016 900 BEAD CORE (86-019-A)
415-HV3500K-090
1
L116 00D 941 0048 307 BEAD (RH03506BT-B)
415-DMC370E3-134
1
MD101 00D 941 0048 404
3P OPTICAL TRANSMITTING CONNECTOR
420-900-205
1
T901 00D 958 0020 705 COIL (P-7GB)
415-RCC955A-091
1
W302 - 3P CONNECTOR WIRE (L=160)
404-390-2167
1*
X101 00D 958 0015 600 CRYSTAL (16.9344MHz)
427-KC710-019
1
IC01 - HEAT SINK
425-390-093
1*
IC03 - HEAT SINK
425-P22-070
1
FUSE02,03
00D 941 0051 103 CHIP FUSE for 390BKE3/290BKE3/
27BKE3
422-MH2-076
2*
FUSE04,05
00D 941 0051 200 FUSE T3.15/250V type:392
for 500AEBKE2/500AESPE2
422-500E2-088
2*
