34
DCM-390/290/27/500AE
12 00D 941 0050 308 TRAY ASS'Y
701-DCM280-3311
1
12-1 - CORRECTING LEVER ASS'Y
701-KMD550-1593
1
12-2 - WHEEL
100-KMD280-729
4
12-4 - MIDDLE GEAR
100-KMD280-733
1
12-5 - TRANSFER GEAR
100-KMD280-736A
1
12-6 - BASE
100-KMD550-1214C
1
12-8 - DRIVE GEAR
100-KMD550-1216
1
12-10 - MOTER FIXED PLATE
300-KMD550-262
1
12-11 - FORWARD GEAR FIXED IRON
300-KMD280-305
1
12-14 - FIXED SHEET (PVC)
501-KMD550-1146
4
12-15 - COMMENTING SPRING
603-KMD550-199
1
12-16 - WASHER
606-H900-052
1
12-17 - FIXED CENTER WASHER
606-C426-066
1
12-18 - MUTE SHEET
612-KMD510-032
1
12-19 - SCREW
602-M100-032
1
12-20 - SCREW (M3X8mm BTP)
602-2002-077
1
12-21 - SCREW (M3X9mm PTP)
602-SL24F-097
1
12-22 - SCREW (2.6X8PTP)
602-SL24F-099
1
12-23 - SCREW (TTP 3X10 ZK PTP)
602-MK7-131
1
12-24 - SCREW (2.6X5.5mm)
602-KM300-144
1
12-25 - SCREW (M2.6X3mm)
602-KM500-155
2
12-26 - SCREW (TTP M2.6X6 PTP)
602-KMD510-158
1
12-27 - SCREW (TTP 2.6X7 CAP 10Z)
602-DV300-5023
3
15 00D 941 0043 001 DISK ASS'Y
701-KMD550B-1900
1*
15-1 - DISK
100-KMD550-1215A
1
15-2 - FIXED SHEET
501-KMD550-1099
1
40 00D 941 0043 409 MOTOR SPIRAL GEAR ASS'Y
704-390-6331
1*
40-1 - SPIRAL GEAR
100-KMD280-731A
1
40-2 - SHAFT
200-KMD280-174
1
40-3 - MOTOR (MEN-7E2T5,DC12V)
401-MK7-043A
1
13-1 00D 958 0003 405 LEAF SW (LSA-1119H,2PIN)
403-DM11A-020
1
13-2 00D 958 0002 105 LEAF SW (LSA-2127E,3PIN)
403-KMD280-048
1
14-1 00D 958 0003 803 PHOTO TRANSISTOR PCB ASS'Y
704-DCM270X-1797
1
14-2 00D 958 0002 008 INFRARED EMITTING PCB ASS'Y
704-DCM270X-1798
1
14-3 00D 958 0003 405 LEAF SW (LSA-1119H,2PIN)
403-DM11A-020
1
14-4 00D 958 0005 704 LEAF SW (LSA-1119F,2PIN)
403-KMD550-087
1
16 - SWITCH CONTROL
100-KMD280-730
1
17 - BOTTOM BASE
100-KMD550-1213A
1
18 - DISK HOLDER
100-KMD550-1219
1
19 - L.FIXED PLATE
300-KMDV280C-263A
1
20 - R.FIXED PLATE
300-KMDV280C-264A
1
21 - STAY R
300-KMD280-265RA
1
22 - STAY L
300-KMD550-265L
1
23 - SWIVEL PLATE
300-KMD550-466
1
24 - MAIN PCB BRACKET
300-390-486A
1*
25 nsp 00D 941 0043 108 FOOT ASS'Y
701-390-3728
4*
25-1 - FOOT (ABS,KURZ BM82361)
100-390-2374
4*
25-2 - FOOT
612-DCM370-067
4
26 - LASER BEAM LABEL
501-1033-428
1
27 - STEEL WIRE
603-KMD280-200
1
28 00D 958 0001 708 MOTOR BELT
604-KMD280-094
1
29 - WASHER (HIMERON BLACK 18)
612-KT300-007
1
30 -
MAGNET (Φ30X18X5t,650Gm)
613-MK7-002A
1
31 - SCREW (TTP CAP M3X8mm)
602-B600-056
2
32 -
SCREW (SAE1018,BTP,Φ3X8)
602-2002-077
6
33 - SCREW (M3X7 PTP)
602-SL24F-096
1
Ref. No. nsp Part No. Part Name Remarks Q'ty New
