DCM-390/290/27/500AE
14-4
◆
LEAF SW (LSA-1119F,2PIN) COMPLEX 1
15-1 DISK ABS 1
15-2 FIXED SHEET PVC 1
16 SWITCH CONTROL POM 1
17 BOTTOM BASE ABS 1
18 DISK HOLDER PVC 1
19 L.FIXED PLATE SPCC 1
20 R.FIXED PLATE SPCC 1
21 STAY R SPCC 1
22 STAY L SPCC 1
23 SWIVEL PLATE SPCC 1
24 MAIN P.W.B. BRACKET SPCC 1
25-1 FOOT (ABS,KURZ BM82361) ABS 4
25-2 FOOT EVA 4
26 LASER BEAM LABEL PAPER 1
27 STEEL WIRE SUS 1
28 MOTOR BELT RUBBER 1
29 WASHER (HIMERON BLACK 18) FELT 1
30
MAGNET (Ф30X18X5t,650Gm)
FERRITE 1
31 SCREW (TTP CAP M3X8mm) SWCH 2
32
SCREW (SAE1018,BTP,Ф3X8)
SWCH 6
33 SCREW (M3X7 PTP) SWCH 1
34 SCREW (M3X9mm PTP) SWCH 1
35
SCREW (SAE1018,PTP,Ф2.6X8)
SWCH 1
36 SCREW (M2.6X4 P0.45) SWCH 2
37 SCREW (PTP M3X14) SWCH 1
38 SCREW (W BTP 2.6X6 MC) SWCH 2
39 CD DOOR ABS 1
40-1 SPIRAL GEAR POM 1
40-2 SHAFT CU 1
40-3
◆
MOTOR (MEN-7E2T5,DC12V) COMPLEX 1
41 BRACKET TRANSFORMER SPCC 2
42 POWER SWITCH BRACKET SPCC 1
43 BUTTOM BASE SPCC 1
44 BACK BOARD SPCC 1
45 TOP COVER PVC+SPCC 1
46
◆
POWER SW (SDDLB1017U-HF,2PIN) COMPLEX 1
48 TRANSFORMER (AC230V) COMPLEX 1
49
◆
AC CAPACITOR (0.01uF/250V,M,BULK,Y5V) COMPLEX 1
50 TRANSFER SCREWS LABEL PAPER 1
52 FUSE LABEL (46X6mm,y=0.08mm) POLYESTER 1
53 CNR COVER (HU-13A-PRW) PVC 1
54 PROTECTION MAT CR FOAM 5
55-1 MOTOR PULLEY PA 1
55-2
◆
MOTOR (MEN-7E2T5,DC12V) COMPLEX 1
56
CUSHION (EVA,Ф31.3,t=1)
EVA 1
57
SCREW (SAE1018,BTP,Ф3X8)
SWCH 4
58 SCREW (3X5mm,BLACK) SWCH 4
59 SCREW (TTB M3X10mm) SWCH 1
60 SCREW (3X8mm) SWCH 18
61 SCREW (TTB M3X12mm) SWCH 4
62 SCREW (4X8mm TTB BLACK) SWCH 2
63 SCREW (3X8) SWCH 4
64 PC WASHER PC 1
65 PC WASHER PC 1
Ref. No. nsp Part Name Material Q'ty
