Denon DN-C680 - Parts List of Exploded View

40
40DN-C680
PARTS LIST OF EXPLODED VIEW
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
Note: The symbols in the column "Remarks" indicate the following destinations.
E3: U.S.A. & Canada model E2: Europe model
Ref.No. Part No. Part Name Remarks Q'ty New
1 GU-3578 MAIN PWB UNIT ASS'Y 1 *
1-1 MAIN UNIT
1-2 DIGITAL I/F UNIT
1-3 AUDIO UNIT
2 GU3001B DISPLAY/KEY PWB UNIT ASS'Y 1
2-1 KEY LED PWB UNIT
2-2 FLT PWB UNIT
2-3 H/P PWB UNIT
2-4 JOG SHUTTLE PWB UNIT
2-5 SELECT SW PWB UNIT
2-6 TRANS PWB UNIT
3 411 1360 305 CHASSIS 1
4 449 0050 064 CARD SPACER 8
5 415 9016 064 P.C.B HOLDER 1
6 461 0911 006 FOOT SHEET 2
7 412 4214 008 TRANS BRACKET 1
9 412 4216 006 PWB BRACKET (A) 1
10 105 1228 102 BACK PANEL 1
11 414 0811 003 BLIND PLATE 1
12 479 0003 025 PUSH RIVET 10
 13 513 3826 004 E2 LASER CAUTION for E2 1
! 14 203 3962 003 AC INLET 1
 15 203 5169 011 3P VH CONN.CORD CN031 1
16 203 0657 023 1P TERMINAL WIRE W011 1
17 412 4217 005 PWB BRACKET (B) 1
! 18 233 6219 000 POWER TRANS T401 1
 19 513 1869 005 CAUTION LABEL 1
! 20 206 1039 034 FUSE 1A for E3, for F401 1
! 20 206 1015 045 FUSE 315mA for E2, for F401 1
! 21 206 1039 063 FUSE 2.0A T for E3, for F402 1
! 21 206 1015 061 FUSE 2A for E2, for F402 1
 22 513 1220 000 CAUTION LABEL 1
27 412 9371 001 SPRING PLATE 1
28 204 2957 009 7P EH CONN.CORD CN072 1 *
29 009 0105 038 25P FFC CABLE CN251 1
30 144 2526 141 FRONT PANEL 1 *
31 441 1822 103 INNER PANEL ASS'Y 1
32 146 0919 002 KNOB GUIDE 1
33 146 1674 003 WINDOW 1
34 461 0912 005 SHEET 2
35 119 0090 107 RUBBER KEY (A) 1 *
36 119 0091 106 RUBBER KEY (B) 1 *
 37 009 0148 008 24P FFC CABLE (TURN) CN241 1
 38 445 0048 016 CORD HOLDER (L50) 1
39 412 4188 008 H/P BRACKET 1
 40 445 8028 009 CORD HOLDER 2
42 113 1188 227 P.S. LEVER ASS'Y 1
43 113 1642 019 JOG DIAL 1
44 112 0909 019 SELECT KNOB A 1
45 112 0555 007 VOL KNOB (B) 1
47 102 0565 142 TOP COVER 1
48 412 4087 002 MOUNTER 2
