25SYS-T3L/SYS-C3L/SYS-A3L/SYS-A2.1L/SC-T3L/SC-A3L/DSW-3LSC-A3L Section

SC-A3L PACKING VIEW

for U.S.A., Canada & Europe model

SC-A3L PARTS LIST OF PACKING & ACCESSORIES

for U.S.A., Canada & Europe model

＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。

Note: The symbols in the column "Remarks" indicate the following destinations.

E3: U.S.A. & Canada model E2: Europe model

Ref.No. Part No. Part Name Remarks Q'ty New

1 9H3 0001 347 SC-A3L 390125 1 *

2 9H3 0001 158 PLASTIC BAG 387969 1

3 9H3 0001 358 POLY FOAM 388007 2 *

4 9H3 0001 306 POLY BAG 383002 1

5 9H3 0001 177 FOOT 381362 1

6 9H3 0001 308 CORD 388271 1 *

7 515 0921 209 S.S.LIST(EX) 368272 1

8 9H3 0001 328 MANUAL 392140 1 *

9 9H3 0001 327 GIFT BOX 390509 1 *

10 515 0944 008 WARRANTY (HOME) for E3 390071 1

11 - CONTROL CARD 390079 2

12 - BAR CODE LABEL (UPC) for E3 390235 1

13 - BAR CODE LABEL (EAN) for E2 390237 1
