Do not expose the speakers and amplifier / mixer for water / liquid or high
humidity. This can permanently damage the units and can be dangerous
because of the power of the amplifier.
Specifications:
System System Type: Powered mixer with 2 two-way bass-reflex enclosures
Frequency Range : 20 Hz - 18 kHz
Amplifier Power: 2*100W
Mixer Output Connector: 2 x 1/4” TS (unbalanced) amplifier output
Input Connectors: 8 inputs (4 Mono Mic/Line, 2 x Stereo)
Channels:
1-4 are XLR / 1/4” jack combo connectors, XLR is a mic level input,1/4” is a
line level input.
5-6, one pair of 1/4”balanced TRS jacks (stereo), and a pair of RCA jacks
(stereo).
7-8 is a 3.5 mm stereo jack
Input Impedance:
Ch 1-4 Combo: XLR 3 K Ohms Balanced
Ch 1-4 Combo: TRS 20 K Ohms Balanced
Ch 5-6 TRS 25K Ohms Balanced
Ch 5-6 RCA 12K Ohms Unbalanced
Ch 7-8 3.5mm 30K Ohms Unbalanced
Speaker LF Driver: 1 10” Woofer 40oz 2” VC 4Ohm
HF Driver: 1” Ti Diap. 8Ohm
Handles: One on top.
