PARTS LIST
MODEL 35-R
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 10 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 115286-01 Burner 1
2 114121-01 Thermocouple 1
3 117384-01 Thermocouple Bracket 1
4 115291-01 Ignitor Electrode 1
5 117385-01 Ignitor Bracket 1
6 102445-01 Piezo Ignitor Kit 1
7 115287-01 Orifice 1
8 115285-01 Valve 1
9 115289-01 Junction Block 1
10 115288-01 Tip Switch 1
11 111090-02
Brass Elbow 1
12 115290-01 Hose/Regulator Assembly 1
13 115292-01 Wheel 2
14 114156-02 Axle Bracket 2
15 115294-01 Wheel Lock 2
16 117297-01 Main Frame Lower Assembly 1
17 117310-01 Reflector 1
PARTS AVAILABLE - NOT SHOWN
114245-06 General Information Decal 1
115297-01 Warning Tag
1
114246-03
Caution Decal 1
