PARTS LIST
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 27 of this manual.
PART NUMBER
KEY EFS33NRB EFS33PRB
NO. VSGF33NRB VSGF33PRB DESCRIPTION QTY.
1a 110881-04 110881-04 Front Log 1
1b 110881-05 110881-05 Middle Log 1
1c 110881-06 110881-06 Rear Log 1
2 099387-12 099387-12 Pilot Tube 1
3 M11084-26 M11084-26 Hex Screw, #10 2
4 098304-01 098304-01 Screw, #10 Phillips, Black 8
5 103779-01 103778-01 O.D.S. Pilot (Propane/LP) 1
6 098249-01 098249-01 Nut 4
7 101006-02 101006-02 Pilot Bracket 1
8 101330-05 101330-05 Front Burner Assembly 1
9 109824-02 109824-02 Rear Burner Assembly 1
10 ** ** Base Assembly 1
11 098271-10 098271-10 Ignitor Cable 1
12 ** ** Firebox Bottom 1
13 1102445-01 102445-01 Piezo Ignitor 1
14 101004-08 101004-01 Front Burner Injector 1
15 104241-02 104241-02 Switch Bracket 1
16 103782-01 103782-01 Valve Bracket 1
17 103284-03 103284-03 Wiring Harness 1
18 102846-02 102846-02 Burner Tube 1
19 097809-02 097809-02 Adapter 1
20 M12461-26 M12461-26 10/32, Screw 4
21 098265-02 098265-02 Elbow, Male 1
22 103781-01 103781-02 Gas Valve Assembly 1
23 099998-01 099998-01 Switch 1
24 101004-14 101004-15 Rear Burner Injector 1
25 101628-03 101628-03 Flex Hose 1
26 M11084-38 M11084-38 Screw 2
27 901056-01 901056-01 3/8" Flare x 1/2" NPT 1
PARTS AVAILABLE — NOT SHOWN
100563-01 100563-01 Warning Plate 1
103877-01 103877-01 Lighting Instructions Plate 1
**Not a field replaceable part.
