113132-01B 31
PARTS LIST
FIREPLACE MODELS
EFS33NRB, VSGF33NRB, EFS33PRB AND VSGF33PRB
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 27 of this manual.
KEY
NO. PART NUMBER DESCRIPTION QTY.
1 101357-01 Top Outer Casing 1
2 103207-01 Outer Casing 1
3 102758-02CK Right Front Side 1
4 102759-02CK Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 17
6 101351-01CK Top Front 1
7 102455-18 Louver 2
8 101353-01CK Middle Front Rail 1
9 101712-02 Firebox Hood 1
10 101348-01 Firebox Support 2
11 099230-01 Shoulder Screw 4
12 101872-03 Firebox Top 1
13 ** Outer Base 1
14 ** Firebox Wrapper 1
15 101514-01 Cover 1
16 M11084-26 Hex Screw, #10 57
17 098304-02 Phillips Pan Head Screw, #6-20x.38 4
18 101727-03 Screen Assembly 1
PARTS AVAILABLE — NOT SHOWN
100639-01 Caution Decal 1
103590-01 Decal Strip 1
104313-01 Hinge, Pin 1
104313-02 Hinge, Pin 1
M10908-2 Screw, Slotted Hex Head Tapping 4
**Not a field replaceable part.
