112126-01B
For more information, visit www.desatech.com
For more information, visit www.desatech.com
35
35
PARTS LIST
MODELS
SDVBND, SDVBPD
This list contains replaceable parts used in your burner system.
When ordering parts, follow the instructions listed under Replace-
ment Parts on page 33 of this manual.
PARTS LIST
Models SDVBND and SDVBPD
KEY PART
NO. NUMBER DESCRIPTION QTY.
1
**
Firebox Assembly 1
2 105795-01 Glass Door Assembly 1
3
**
Rear Cover 1
4 M11084-46 Screw, Hex 19
5 107191-01 Baffle 1
6 M12461-73 Screw 2
7 101480-12 Wire Assembly 1
8 104491-01 Relief Cover 1
9 104518-01 Relief Cover Gasket 1
10 104527-01 Relief Spring 2
11 104528-01 Relief Washer 2
12 H5C4-20B Hex Head Cap Screw 2
13 NTC-4C Locknut 2
14 105468-02CK Valve Bracket 1
15 104496-01 Valve, Natural 1
104496-02 Valve, Propane/LP 1
16 105486-01 Pilot Assembly, Natural 1
105486-02 Pilot Assembly, Propane/LP 1
17 102445-01 Ignitor, Piezo 1
18 107014-01 Center Cast Stove Top Grate 1
19 106036-01 Burner, Natural 1
106036-02 Burner, Propane/LP 1
20 104506-16 Orifice, Natural 1
104506-17 Orifice, Propane/LP 1
21 104507-01 Brass Elbow 1
22 097809-03 Brass Fitting 2
23 101628-04 Flex Tubing 2
24 106794-01CK Grate Assembly 1
25 105325-01 Air Deflector 1
26 105491-01 Log Set 1
26-1 105774-01 Rear Log 1
26-2 105774-02 Log 1
26-3 105774-03 Crossover Log 1
26-4 105774-04 Log Piece 1
27 098304-03 Screw 2
28 M12461-25 Screw 4
PARTS AVAILABLE - NOT SHOWN
GA6060 Lava Rock 1
112044-01 Ember Material Bag 1
112043-01 Blower Bracket Screw Assembly 1
** Not a field replaceable part.
