www.desatech.com
116192-01M 41
PARTS
BURNER ASSEMBLY MODELS
TC36N, VTC36N, TC36P AND VTC36P SERIES
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 37 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 ** Burner Pan Assembly 1
2 ** Base Grate 1
3 ** Firebox Base Bottom 1
4 26808 Valve Bracket 1
5 11107 Screw, #10-32 x 1/4 Zinc 4
6 ** Firebox Bottom 1
7 11102 Screw, #8-32 x 3/8 Zinc 2
8 121877-01 Aluminum Tubing Assembly 1
9 111288-02 Flex Gas Line 1
10 108084-02 Pilot Assembly NG 1
108084-03 Pilot Assembly LP 1
108084-05 Pilot Assembly (-HA Models) 1
11 14389 Natural Gas Valve 1
14390 Propane/LP Gas Valve 1
117370-01 Natural Gas High Altitude Valve 1
12 11165 Screw, #10 x 5/8 Zinc 23
13 ** Burner Base Gasket 1
14 14500 Brass Fitting 2
15 116345-01 Pilot Bracket 1
16 26827 Switch Bracket 1
17 11226 Flat Washer 7/8" ID x 2" OD 2
18 11214 Bulkhead Fitting with Washer 2
19 14296 Elbow 3/8" 1
20 23102 Burner Orice #40 NG 1
23096 Burner Orice #53 LP 1
21 14492 Piezo Ignitor 1
22 14511 Piezo Bracket 1
PARTS AVAILABLE - NOT SHOWN
108085-03 Pilot Injector #62 (-HA Models Only) 1
**Not a eld replaceable part.
