Desa VM42P - Parts List

www.desatech.com
108795-01N 27
PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 22 of this manual.
** Not a field replaceable part.
KEY
NO.
M36(B,H)
VM36(B,H)
M42(B,H)
VM42(B,H)
DESCRIPTION
QTY
1 14153 14153 Micro Switch 1
2 ** ** Insulation Pan 1
3 ** ** Fireplace Top
Assembly
1
4 ** ** Fireplace
Surround
1
5 106642-01 106642-01 Air Rod
Retainer
1
6 106643-01 106643-01 Damper Rod
Retainer
1
7 106651-01 107805-01 Panel Closure 2
8 ** ** Firebox
Bottom
1
9 ** ** Firebox
Surround
1
10 106657-02 107811-02 Air Separator 1
11 11408 11408
Bushing 2
12 See page 28 Left Refractory 1
13 See page 28 Right Refractory 1
14 See page 28 Rear Refractory 1
15 See page 28 Bottom Rear
Refractory
1
16 See page 28 Bottom Front
Refractory
1
17 ** ** Firebox
Support Leg
2
18 106687-01 106887-02 Damper Can
Collar
1
19 106691-01 107839-01 Screen Rod 2
20 ** ** Firebox Top
Assembly
1
21 106699-01 106699-01 Transition 6"
B-Vent Collar
1
22 106703-01 106703-01 Air Kit Door
Assembly
1
23 ** ** Firebox Face 1
24 106948-02 107823-02 Smoke
Deflector
1
25 ** ** Fireplace Top
Insulation
1
26 107796-01 107796-02 Grate
Assembly
1
27 107742-01 107742-02 Burner Pan 1
28 107795-01 107831-01 Burner Tube 1
29 107748-01 107748-01 Burner
Bracket
1
30 107985-01 107985-02 Pilot Shield 1
31 901681-01 901681-01 Burner Clamp 1
32 11209 11209 Nut, #10-24 1
33 11147 11147 Screw, #10-
24 x 1/2
1
34 901066-01 901066-01 Brass Air
Mixer (NG)
1
901066-02 901066-02 Brass Air
Mixer (LP)
1
KEY
NO.
M36(B,H)
VM36(B,H)
M42(B,H)
VM42(B,H)
DESCRIPTION
QTY
35 901064-03 901064-08 Orifice (NG) 1
901065-13 901065-12 Orifice (LP) 1
36 108084-01 108084-01 Pilot (NG) 1
108084-03 108084-03 Pilot (LP) 1
37 108085-01 108085-01 Pilot Orifice
(NG)
1
108085-02 108085-02 Pilot Orifice
(LP)
1
38 11102 11102 Screw, #8-
32 x 3/8
2
39 14512 14512 Gas Control
Valve (NG)
1
14513 14513 Gas Control
Valve (LP)
1
40 107741-01 107741-01 Valve Bracket 1
41 14261 14261 Piezo Ignitor 1
42 111288-02 111288-02 Manual Valve
w/ Flex Hose
1
43 108769-01 108769-02 Extension
Deflector
2
44 108005-01 108005-01 Wire Harness 1
45 108005-02 108005-02 Wire Harness 1
46 11418 11418 Push-On Nut 2
47 12105 107840-01 Screen 2
48 14123 14123 Strain Relief 1
49 14574 106543-01 Limit Switch 1
50 ** ** Collar
Insulation
1
51 20023 20488 Starter Collar 1
52 20027 20027 Brick Liner
Retainer
2
53 20042 20042 Air Kit Cover 1
54 20088 20088 Door Stop 1
55 20089 20089 Pivot Clip 2
56 20090 20090 Spring Clip 2
57 20280 20280 Top Spacer 4
58 ** ** Gas Knockout
Cover
4
59 ** ** Gas Conduit 1
60 ** — Gas Conduit 1
61 22912 22924 Draft Diverter 1
62 24353 24353 Box Assembly 1
63 11165 11165 Screw, #10 x
5/8 Mod. Tr.
Blk. Ox
2
PARTS AVAILABLE NOT SHOWN
901155-01 901155-01 Vermiculite
Bag
1
901156-01 901156-01 Pan Material 1
901157-01 901157-01
Lava Rock 1
22180 22180 Wall Switch
Kit
1
