Remove cover cap from headboard tie rail. Undo nut and remove. Insert speaker
bracket in the orientation shown and re-attached nut, tighten in a clockwise
direction using spanner provided. See step 5 for method of attaching speakers to
speaker bracket.
5
Remove the speaker stem from the speaker as shown. Align the speaker
screw hole with the corresponding fork detail on the bracket. Fasten
speaker using the flat washer provided and screw from speaker stem
assembly as shown below. Feed speaker cable through the cable ties on
the rear of the headboard.
Screw
Remove cover cap from headboard tie rail. Undo nut and remove. Insert
speaker bracket in the orientation shown and re-attach nut, tighten in
a clockwise directionusing spanner provided. See step 5 for method of
attaching speakers to speaker bracket.
6
