If none of the above causes is found, the problem may exist in the main board internal
circuits or in the mother board processor. The main board should be replaced.
3.1.2. NTC (10kOhms@25°C/77°F) Diagram
-40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90 100
[kOhms]
[°C]
kOhmsVsTemp Chart - NTC
10kOhms
PROBE
S
TERMINAL
BLOCK
STANDARD
VERSION
TOUCH SCREEN
VERSION
