Desoutter 3747 - CAD Files Availability; Product Overview and Technical Data

Product Information EN
4 / 12 06/2020
mm in.
B 199 7.83
C 120 4.72
CAD files
For information about the dimensions of a product, see the Dimensional drawings archive:
https://www.desouttertools.com/resource-centre
Overview
Description
1 Battery charge level
2 Warning LED
3 Connector
4 Daisy-chain output
4 Power supply plug
Technical data
Power supply
Input voltage 100-240 V AC
Frequency 50 / 60 Hz
Maximum input current single: 2 A
daisy-chain: 6.3 A
Output voltage 0-42 V DC
Output current 2 A
Maximum number of chargers connected in daisy-chain 10 @ V
IN
= 230 V AC
5 @ V
IN
= 115 V AC
Weight
0.665 kg
1.47 lb
Storage and use conditions
Storage temperature -20 to +70 °C (-4 to +158 F)
Operating temperature 0 to 45 °C (32 to 113 F)
Storage humidity 0-95 % RH (non-condensing)
Operating humidity 0-90 % RH (non-condensing)
Altitude up to 2000 m (6562 feet)
Usable in Pollution degree 2 environment
