DATA
ECS
Model Part number Output
Torque (Nm) Torque (ft.lb)
Speed
(rpm)
Weight
Min Max Min Max kg lb
ECS06 6151654420 Hex ¼” 0.12 0.6 0.088 0.442 2000 0.6 1.32
ECS2 6151654430 Hex ¼” 0.45 1.8 0.331 1.326 2000 0.6 1.32
ECS4 6151654450 Hex ¼” 1.0 4 0.737 2.95 2000 0.6 1.32
ECS7 6151654460 Hex ¼” 1.9 7.5 1.38 5.53 1800 0.7 1.54
ECS10 6151654440 Hex ¼” 2.5 10 1.84 7.37 1340 0.7 1.54
ECS16 6151654590 Hex ¼” 4 16 2.94 11.78 840 0.7 1.54
285
209
24
4000
Ø36
Ø40.4
50.6
