Desoutter ECS06 - Page 5

6159928110_01
5 / 6209/2019
DATA
ECS-M20
Model Part number Output
Torque (Nm) Torque (ft.lb)
Speed
(rpm)
Weight
Min Max Min Max kg lb
ECS06-M20 6151654540 Hex ¼” 0.12 0.6 0.088 0.442 2000 0.6 1.32
ECS2-M20 6151654550 Hex ¼” 0.45 1.8 0.331 1.326 2000 0.6 1.32
ECS4-M20 6151654560 Hex ¼” 1.0 4 0.737 2.95 2000 0.6 1.32
ECS7-M20 6151654570 Hex ¼” 1.9 7.5 1.38 5.53 1800 0.7 1.54
ECS10-M20 6151654580 Hex ¼” 2.5 10 1.84 7.37 1340 0.7 1.54
ECS16-M20 6151654600 Hex ¼” 4 16 2.94 11.78 840 0.7 1.54
285
209
24
20
4000
Ø36
Ø40.4
50.6
