Desoutter ECS06 - Page 6

6159928110_01
6 / 62 09/2019
Model Part number Output
Torque (Nm) Torque (ft.lb)
Speed
(rpm)
Weight
Min Max Min Max kg lb
ECSA2 6151654470 Hex 1/4” 0.55 2.0 0.405 1.474 2000 0.6 1.32
ECSA7 6151654480 Hex 1/4” 2.2 8.5 1.621 6.26 1500 0.7 1.54
ECSA10 6151654490 Hex 1/4” 3 11.5 2.21 8.47 1150 0.7 1.54
DATA
ECSA
329
4000
242.55 24
Ø36 Ø40.4
50.6
6.2
40.7
