53
Step 3:Programming Zone Partition Assignments
Addresses 1248-1311
DS7400Xi Panel Wiring & Programming
Partition Assignment Address
For Zones 1 and 2 1248
For Zones 3 and 4 1249
For Zones 5 and 6 1250
For Zones 7 and 8 1251
For Zones 9 thru 128 1252-1311
Select Option DD
Belongs to Partition 1
Belongs to Partition 2 1
Belongs to Partition 3 2
Belongs to Partition 4 3
Belongs to Partition 5 4
Belongs to Partition 6 5
Belongs to Partition 7 6
Belongs to Partition 8 7
0
Select Option DD
Belongs to Partition 1
0
Belongs to Partition 2 1
Belongs to Partition 3 2
Belongs to Partition 4 3
Belongs to Partition 5 4
Belongs to Partition 6 5
Belongs to Partition 7 6
Belongs to Partition 8 7
Data Digit
1 2
Odd-numbered zones
Even-numbered zones
