54
Data Digit
DS7400Xi Panel Wiring & Programming
1 2
Enter the Data Digit as a:
Select Options 0
1 2 3 4 5 6 7 8 9 *0 *1 *2 *3 *4 *5
Zone Function 1 Can Be Bypassed
*
0 -
*
5 are Hex values. They will display as A-F at keypads.
Zone Function Bypass Programming
Zone Function 2 Can Be Bypassed
Zone Function 3 Can Be Bypassed
Zone Function 4 Can Be Bypassed
Enter the Data Digit as a:
Select Options
0 1 2 3 4 5 6 7 9 *0 *1 *2 *3 *4 *5
Zone Function 5 Can Be Bypassed
Zone Function 6 Can Be Bypassed
Zone Function 7 Can Be Bypassed
Zone Function 8 Can Be Bypassed
Program Address 0016
8
To Next Page
