1. Service Cover
2. ATS Wiring Harness
3. ATS Delta Pressure Sensor
4. Inlet NOx Sensor
5. ATS Delta Pressure Tube
Figure 11. ATS Top View
1. DPF Outboard Clamp
2. DOC Inlet Temperature Sensor
3. DOC Outlet Temperature Sensor
4. DPF Inboard Clamp
5. DPF
Figure 12. ATS Side View
