HINGE ADJUSTMENT
If the door do not appear square or aligned,loosen or tighten the appropriate screws on each case
hinge as illustrated.
Loosen screw ( Do not loose screw to the end), push hinge arm forwards or backwards,
re-tighten screw .
B
B
1 2
DEPTH ADJUSTMENT
B
B
C
B
Adjust screw to make hinge move left or right to the ideal place.
C
SIDE TO SIDE ADJUSTMENT
