When installing, please make sure the screws are flattened, Not crooked;
Otherwise the drawers will not be installed perfectly.
Please do not install the bottom drawer runner part in this step, Otherwise
it will not be able to install the connector housing ( Part C ), the bottom
drawer runner part will be installed in
step 7.
REMARK
X16E
M4x14
X4
CL
X4
CR
CL
CR
TOP
BOTTOM
