DEVAISE S-ASNG010 - Cabinet Door Hinge Adjustment Guide; Adjusting Cabinet Door Depth; Adjusting Cabinet Door Side Clearance

C
B C B
If the door do not appear square or aligned,
loosen or tighten the appropriate screws on each case hinge as illustrated.
Loosen screw B and screw C( Do not loose screw C to the end), push
hinge arm forwards or backwards, re-tighten screw B.
Adjust gap with screw C.
21/21
HINGE ADJUSTMENT
Depth adjustment:
Side to side adjustment:
B
