3.
E
×16
CL
×4
CR
×4
×16
When installing, please make
sure the screws are flattened,
Not crooked; Otherwise the
drawers will not be installed
perfectly.
REMARK:
Please do not install the bottom drawer runner part in this step,
Otherwise it will not be able to install the connector housing
( Part E ), the bottom drawer runner part is installed in step 7.
NOTE：
BOTTOM
TOP
FRONT
FRONT
FRONT
CR
6/21
3
4
E
E
CR
CL
CL
CL
CL
CR
CR
CR
