Product Guide ineo
+
224/284/364/454/554
JOB SEPARATOR JS-602 Option for FS-535
Function
Additional 3
rd
bin for FS-535
Paper Weight
60 – 90 g/m²
Paper Size
A5 – A3W (311 x 457 mm)
Stacking Capacity
Max. 100 sheets (60 – 90 g/m²)
Dimensions (WxDxH) (mm)
341 x 537 x 149
Weight (kg)
1.75
Remark
Cannot be used together with PI-505
INNER JOB SEPARATOR JS-506 Option
Paper Size
Tray 1/2: A6 to SRA3, Banner and Long Length Tray 2 only
Paper Weight
Tray 1/2: 52 – 300 g/m²
Capacity
Tray 1: 150 sheets (90 g/m²)
Tray 2: 50 sheets (90 g/m²)
Dimensions (WxDxH) (mm)
491.9 x 469.5 x 226.5
Weight (kg)
1.5
POST INSERTER PI-505 Option for FS-535
Function
Pre-printed page insertion, manual stapling, half fold and punching
Paper Size
Upper Tray: A5 lengthwise up to A4 (B5)
Lower Tray: A5 lengthwise up to A3+ (311 x 457 mm)
Paper Weight
60 – 209 g/m²
Capacity
Max. stack capacity 200 sheets 80 g/ m²
Dimensions (WxDxH) (mm)
511 x 635 x 220
Weight (kg)
10,5
Remark
Cannot be used together with JS-602
