26
FIGURES, DIAGRAMS, AND VIEWS
Bib Screws
Figure 4A. Interior Rear View (early OSD models)
Cooling Fan
Mounting Plate Screw
Pressure Exhaust Hose
(Silicone) 1/2" ID
Compressor
Strain Relief on
115 volt units.
IEC Power Connector on 230 volt units.
Compressor Electrical Connector
Accumulator Tank
Exhaust Muffler
(Hidden)
Intake
Filter
Communication Port
(OSD units only)
Oxygen Sensor Assembly
(OSD units only)
Compressor Filter
Motor Mount
Compresssor
Mounting Plate
