SPECIFICATIONS
DEVILBISS 4-LITER DEVILBISS 5-LITER SERIES
Catalog Number 5
11
5UK 5
11
5DZ, 5
11
5DS 5
11
5KZ, 5
11
5KS, 5
11
5NS
Delivery Rate (Lower delivery rates 1 to 4 LPM 1 to 5 LPM
available for low flow applications)
Maximum Recommended Flow 4 LPM 5 LPM
Outlet Pressure 8.5 psig (58.6 kPa)
Electrical Rating 230V, 50 Hz,
1.4 Amp 115V, 60 Hz, 4.2 Amp 220-230V~, 50 Hz, 1.7 Amp
230V~, 60 Hz, 1.9 Amp
Operating Voltage Range
195 - 253V~, 50 Hz 97 - 127V~, 60Hz 187 - 255V~, 50Hz
218 - 253V~, 60 Hz
Oxygen Percentage 1 - 4 LPM=93% ±3% 1 - 5 LPM=93% ±3%
Operating Altitude
(tested at 2
1°C only) Across the voltage range: Across the voltage range: Across the voltage range:
0 - 1500 M (0 - 4921 ft) No degradation in performance No degradation in performance No degradation in performance
Tested at nominal voltage only: Tested at 230V/50Hz only:
1500- 3000 M (4921 - 9842 ft) Not recommended / Not tested No degradation in performance ~4% oxygen performance drop at 5LPM
3000 - 4000 M (9842 - 13,123 ft) Not recommended / Not tested Not recommended / Not tested Not recommended / Not tested
Operating Environment Range* No degradation in performance across
~4% oxygen performance drop at 5 LPM
10°C to 35°C, the operating voltage range
and 35°C condition. No degradation in
humidity range of 30% to 75% (tested at sea level) per
formance across the operating voltage
range at other liter flows (tested at 670 M).
Power Consumption 295 Watts Average 400 Watts Average 230V/50Hz–365 Watts Average
230V/60Hz–435 Watts Average
Weight 53 lbs. (24.5 Kg) 52 lbs. (23.5 Kg) 53 lbs. (24.5 Kg)
Sound Level
(ISO 8359:1996 from front) 50.5 dbA overall average 52.5 dbA overall average** 50.5 dbA (50Hz) overall avg.
Dimensions 27.75"H x 16"W x 14"D (70.5 x 40.6 x 35.6 cm)
Pressure Relief Valve 44 psig ±3 psig (303 kPa ±21 kPa)
Operating System Time Cycle /
Pressure Swing
For units equipped with an OSD, Units with serial numbers less than H20000: 85% ±2%
the visible “low oxygen” indicator (The audible alarm will alert at approximately 75%.)
will activate at the following levels Units with serial numbers of 20000 and greater: 83.5% ± 1.5%
(The audible alarm will alert at approximately 75%.
Less than 60%, the red “Service Required” light will activate)
Storage and Transport Conditions -40°C to 70°C, humidity range of 10% to 100%, including condensation (tested at ~933 hPa)
Equipment Class and Type Class II Equipment Double Insulated Type B applied Part
Approval Body and TUV CSA TUV
Safety Standard IEC 60
1-1 +A1 + A2 CAN/CSA-C22.2 IEC 601-1 +A1 + A2
EN 6060
1 + A1 + A2 No. 601.1-M90 EN 60601 + A1 + A2
ISO 8359:
1996 ISO 8359: 1996
(515KZ excluded)
EMC Compliance To: IEC 601-1-2
Typical Accumulator Pressure
at Maximum Recommended Flow 50Hz
@ Sea Level
18 - 23 psig (125 - 160 kPa) 22 - 28 psig (150 - 200 kPa) 21-27 psig (145-190 kPa)
@ 750 M (2460 Ft)
16 - 21 psig (110 - 145 kPa) 20 - 26 psig (140 - 180 kPa) 20-26 psig (140-180 kPa)
@
1500 M (4921 Ft) 14 - 19 psig (95 - 130 kPa) 17 - 23 psig (120 - 160 kPa) 18-24 psig (125-165 kPa)
60 Hz
27-33 psig (
190-230 kPa)
24-30 psig (
165-210 kPa)
21-27 psig (110-190 kPa)
Note: Specifications subject to change without notice.
*Note:The OSD performance at 10°C to 35°C, 95% R.H.
through the voltage range has been verified on a 5
15DS
at 670m.
**Note:This corresponds with a sound level of 50 dbA overall
average as measured according to the guidelines of the
now defunct ANSI Z79.13-1981 standard.
