DeVilbiss DAGR - Page 7

Page 7SB-2-055-B
Ref.
No. Order No. Model No. Description
1 802613 DGR-101 Crown cap
2 802615 DGR-103-35 Air cap (for .35mm nozzle)
3 802616 DGR-104 Head cap
4 802618 DGR-105-35 Nozzle (.35mm)
• 5 – – O-ring (head cap & handle)
6 802619 DGR-106K Packing and nut assembly (Teflon)
7 802620 DGR-107 Air valve casing
8 802621 DGR-108K Air valve kit
• 9 – – Air valve washer
10 – – Air valve plunger
11 – – Air valve spring
12 – – Air valve nut
13 802622 DGR-109 Trigger assembly
14 802636 DGR-122K Trigger buttons ergo-pack (4 types)
14a – – Trigger button A (standard)
14b – – Trigger button B
14c – – Trigger button C
14d – – Trigger button D
Ref.
No. Order No. Model No. Description
15 802623 DGR-110K Needle guide, rocker, & spring
16 – – Needle guide and rocker
• 17 – – Needle spring
18 802624 DGR-111 Spring guide
19 802625 DGR-112 Needle locknut
20 802627 DGR-113-35 Needle (for .35mm nozzle)
21 802628 DGR-114 Cutaway handle w/pre-set
• 22 – – O-ring (pre-set needle knob)
23 802630 DGR-116 Pre-set needle knob
24 802631 DGR-117 1/4 oz.(7 cc) cup and lid
25 802632 DGR-118 1/3 oz.(9 cc) cup and lid (standard)
26 802633 DGR-119 1/2 oz.(14 cc) cup and lid
27 802634 DGR-120 Cup lid
28 802635 DGR-121K DAGR repair kit
29 802974 DGR-12-K5 Air valve washer kit (5)
30 802975 DGR-18-K5 O-ring (head cap & handle) kit (5)
Ref. Description Qty.
5 O-ring (head cap & handle) 3
9 Air valve washer 2
17 Needle spring 1
22 O-ring (pre-set needle knob) 1
• DAGR Repair Kit 802635 (DGR-121K) includes:
