DISASSEMBLY/CLEANING INSTRUCTIONS
Step 1
1. Disassemble cup lid.
Catch excess paint inside
tube with a rag.
2. If you have Adapter Kit
KK-5052, see SI-4-20-7
for further instructions.
If not, proceed to Step 3.
Step 3
Step 4
Step 5
3. Remove ring.
4. Pull up on liner.
5. Properly dispose of lid,
liner and waste material.
Save ring.
Step 2
Extreme Explosion Hazard.
Cup or waste container must
be grounded. A static charge
can build during flushing,
potentially igniting the
flammable vapors. Ground
as shown in Step 2.
Hose/Gun
Cleaner
*Ground
Straps
*McMaster Carr
Cat. No. 6955K2
or equal.
