A-650
Important Parts of Your Compressor
7
IMPORTANT PARTS OF YOUR DEVILBISS
COMPRESSOR
(FIGURES A, B & C)
1. Storage compartment
2. Storage compartment door with operating
instructions
3. Power switch
4. Filter cap
5. Air-outlet connector
6. Carrying handle
7. Power cord storage
8. Nebulizer holder
NOTE– Models 4650D & 5650H are equipped with a
three-prong plug and must be grounded. All other
models are equipped with a two-prong plug.
Important Safeguards
A-650
6
2. If it is necessary to use an extension cord, use only a 3-wire extension cord
that has a three-blade grounding plug, and a 3-slot receptacle that will accept
the plug on the unit. If power cord is damaged do not use unit, and contact a
qualified Sunrise Medical provider.
SAVE THESE INSTRUCTIONS
INTRODUCTION
Your doctor has prescribed a liquid medication to treat your respiratory condition. To
best utilize this liquid medication, he has prescribed a DeVilbiss brand
compressor/nebulizer. Your DeVilbiss compressor/nebulizer works to convert the med-
ication to a high-quality mist of fine particles that penetrates deep into the lungs.
Be sure that you read and understand the information in this instruction guide. By fol-
lowing these simple instructions and the advice of your physician, your compressor will
become an effective addition to your therapeutic routine.
Statement of Intended Use
The DeVilbiss compressor/nebulizer is an AC powered air compressor that provides a
source of compressed air for home health care use. The product is used in conjunction
with a jet (pneumatic) nebulizer to convert liquid medication into an aerosol form
with particles smaller than 5 microns diameter for inhalation into the patient's respira-
tory tract for the treatment of respiratory disorders.
The target population for this device consists of both adult and pediatric patients suf-
fering from, but not limited to asthma, cystic fibrosis, and chronic obstructive pul-
monary disease. Further, additional applications for aerosolized medication are con-
stantly under investigation and this device may be deemed suitable for such applica-
tions as prescribed.
The intended environment for use of the product is in the patient's home on the order
of a physician.
1
3
4
2
5
6
1
3
4
2
5
6
1
3
4
2
5
7
7
7
8
8
8
Figure A– 3650
Figure B– 4650
Figure C– 5650
Compressor Figures
6 (on back)
Grounded Outlet Box
Grounded
Outlet
Grounding Pin
Adapter
Tab for
Grounding Screw
A
C
B
