The construction of the rear panel on the 8A is slightly different than the 10A.
1. MP3 player with Bluetooth, USB and SD functionality
(remote control included)
2. Microphone input via TRS jack plug
3. Line input via stereo RCA or mono balanced 3-pin XLR
4. Link output (line signal) via balanced TRS jack plug
5. Speaker output via lockable speaker connector
6. MP3 player volume control /microphone volume
7. Line signal volume control XLR
8. Line signal volume control RCA
9. Echo function (influence on MIC / Line 1)
10. Master volume control
11. Treble tone control (+/-12 dB)
12. Bass tone control (+/- 12 dB)
13. Clip LED indicator
14. Power LED indicator
15. On/off switch
16. IEC C14 power input with
fuse holder
17. Cooling fins
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:10-11-2018 RV Revision date and author's initials: -
