Devine MixPad 502-FX-USB - Specifications

Specifications
General specifications for all models:
- practical and compact PA mixers
- desktop design with clear layout
- suitable for mixing various audio sources
- various inputs and outputs for microphone and line signals
- various options for connecting equipment
- optimal control over all inputs
- robust metal housing with synthetic side panels
- lockable power connector for power adapter unit
- models with and without built-in effects module
- models with and without built-in 2-in, 2-out USB audio interface
Channel strip:
Mono channel strip:
- microphone input via balanced 3-pin XLR
- mono line output via balanced TRS jack or unbalanced TS jack
- trim control
- 3-band EQ with low, mid and high tone controls (80 Hz, 2.5 kHz, 12 kHz, range from -15 to +15 dB with
zero point)
- FX intensity control (-infinite to +15 dB with zero point)
- pan control (far left to far right mix positioning)
- Clip LED indicator
- channel volume control (-infinite to +150 dB with zero point)
Stereo channel strip:
- mono (L) or stereo input (L+R)
- suitable for balanced TRS jack and unbalanced TS jack
- 3-band EQ with low, mid and high tone controls (80 Hz, 2.5 kHz, 12 kHz, range from -15 to +15 dB with
zero point. Please note: not available on all models.
- FX intensity control (-infinite to +15 dB with zero point)
- balance control (far left to far right mix positioning)
- Clip LED indicator
- channel volume control (-infinite to +150 dB with zero point)
Technical specifications per model:
Model 502 602 602-
FX-
USB
802 802-FX-
USB
1002 1002-
FX-USB
1202 1202-FX-
USB
Number of
mono channels
1 2 4 2 4
Number of
stereo
channels
2 4
Dimensions (l
x b x h)
195 x
120 x
42/32
mm
240 x
184 x
42/32
mm
240 x
184 x
47/37.5
mm
240 x
237 x
42/32
mm
240 x
237 x
47/37.5
mm
240 x
208 x
42/32
mm
240 x
208 x
47/37.5
mm
240 x
260 x
42/32
mm
240 x 260 x
47/37.5 mm
Weight 0.7 kg 1.2 kg 1.5 kg 1.3 kg 1.7 kg
Power
consumption
13 W 15 W 17 W 18 W 23 W
The information in this user manual is subject to change at any time without notice.
Version:
1.0
Date of creation and author's initials:04-12-2018 RV Revision date and author's initials: -
