Specifications
– UHF compact wireless microphone system
– 1x / 2x wireless handheld microphones with 1x compact receiver
– operates using the SRD frequency band that can be used freely in the EU (863 – 865 MHz)
– fixed microphone frequencies, no synchronisation required
– dual antenna
– operation range: 20 – 30 metres, provided a clear and unobstructed line of sight is maintained between the
transmitter and receiver, and no devices using the same or similar frequency band are close by.
Handheld microphone
– practical handheld microphone with robust grille
– LCD display screen
– 1 central ON/OFF switch
– powered by 2x AA batteries (included)
– low battery indicator
Receiver:
– dual antenna
– desktop model receiver
– volume control per channel
– signal strength indicator per channel
– link-indicator per channel
– powered by external power supply (included)
– separate balanced 3-pin XLR output per channel
– mixed 6.35 mm TRS jack output for connection to an active speaker or mixer
Technical features:
WM-50 Solo WMD-50 Duo
Number of microphones 1 handheld microphone 2 handheld microphones
Available bodypack versions 1 bodypack + microphones (sold
separately)
2 bodypack + microphones (sold
separately)
Transmission frequency 863.5 MHz 863 + 864 MHz
Dynamic range 96 dB
Distortion < 0.3 %
Frequency range 30 Hz – 20 kHz (+/- 2dB)
Signal-to-noise ratio 96 dB
Reception sensitivity – 95 dB
Transmission delay < 3 ms
Audio outputs 1x 6.35 mm jack mix out
1x balanced 3-pin XLR out
1x 6.35 mm jack mix out
2x balanced 3-pin XLR out
Harmonic distortion < -50 dBc
Transmission strength 10 mW
Average battery lifespan 5 hours
Included batteries 2 4
Handheld battery type 2x AA
Receiver power 12 V DC, 160 mA
Power supply – connection voltage: 100 V – 240 V AC, 50/60 Hz
– output: 12 V DC 500 mA, centre positive.
The information included in this user manual is subject to change at any time and without notification:
Version:
1.0
Date and author initials: 04-08-2020 RV Revision and author initials: -
