Devolo dLAN 85 HSplus User Manual

Appendix
|
|
devolo dLAN 85 HSplus
|
22
4.3 Technical data
Standards
Ethernet specifications IEEE 802.3, IEEE 802.3x, IEEE 802.3u,
Auto MDI / X
backward-compatible to HomePlug standard 1.0
Protocols
CSMA/CA
Transmission speed
85 Mbps
Transmission method
asynchronous
Modulation
OFDM - 84 carriers
Data path
Ethernet <-> power supply grid
Range
up to 200m over power supply grid
Security
DES
pro
encryption over household power supply grid
LEDs
-Power
-Ethernet (Link/Act)
-dLAN (Link/Act/quality)
Socket / connector
DE, NL, ES, PT, AT, SW, FI, NO:
Type F (CEE 7/4) / Type E + F (CEE 7/7 + CEE 7/4)
FR, BE: Type E (CEE 7/7) / Type E + F (CEE 7/7 + CEE 7/4)
UK: Type G (BS 1363) / Type G (BS 1363)
CH: Type J (SEV 1011) / Type J (SEV 1011)
Power output at integrated
socket
230 V / 16 A maximum
Device port
Ethernet RJ45
Power consumption
5 W (max.), 3,3 W in standby
Power supply
AC 100-240V 50/60Hz
Damping filter
2 – 30 MHz
Filter characteristics
-22 dB to -45 dB
Temperature
Storage: -25°C – 70°C
Operation: 0°C – 40°C
Weight
240 g
Dimensions
130 x 66 x 42 mm (height x width x depth)
Ambient conditions
10–90% humidity (non-condensing)
System requirements
Ethernet interface
Operating systems
Windows
®
XP
32-bit
, Windows
®
Vista
32/64-bit
, Linux
®
, Mac OS
®
X and all operating
systems with TCP/IP support
Certifications
CE-compliant in accordance with the technical requirements of all EU countries
and Switzerland:
EN 60950-1:2006
EN 55022:2006
EN 50412-2-1
