| FR |
Bouton PLC
LED PLC L’adaptateur devolo Magic LAN triple ... Comportement de la LED
Durée de pression
du bouton
Action Comportement de la LED
Brille blanc
Clignote blanc rapidement
Brille blanc et clignote rouge
brièvement
Brille rouge
Éteinte
Clignote blanc lentement
Clignote blanc et rouge en alter-
nance
1 seconde
>10 secondes
Commencer l‘appairage avec d‘autres adaptateurs
devolo Magic
... fonctionne correctement. Il est connecté à d‘autres
adaptateurs devolo Magic.
... est en train d‘établir une connexion d’appairage avec
un autre adaptateur.
... a une mauvaise connexion CPL.
... est en cours de démarrage.
... ne détecte pas d‘autres adaptateurs devolo Magic.
... n‘a plus de fonction LED, car elle a été désactivée par
l‘utilisateur.
... n’est pas associé au réseau*
... est en mode veille.
... est en train d’eectuer une mise à jour logiciel.
Réinitialiser l‘adaptateur devolo aux paramètres d‘usine
Clignote blanc
Brille rouge
Clignote rouge
*Voir page 17 pour savoir comment eectuer un appairage manuel.
| US |
PLC button
PLC LED The devolo Magic LAN adapter ... LED behavior
Time button is
pressed
Action LED behavior
Solid white
Fast ashing white
Solid white followed by short
ashing red
Solid red
None
Slow ashing white
Alternating white and red
1 second
> 10 seconds
Start pairing with other devolo Magic adapters
... is working perfectly. It is connected to other devolo
Magic adapters.
... is currently pairing with another adapter.
... has a poor Powerline connection.
... is currently in the start-up process.
... cannot see any other devolo Magic adapters.
... no longer has any LED function since it was disabled by
the user.
... is not connected to the network*
... is in standby mode.
... is currently undergoing a software update.
Reset devolo adapter to factory settings
Flashing white
Solid red
Flashing red
* Go to page 17 for instruction on pairing manually.
