Storage Recommendations
1. The best storage place is one that is cool and dry, away from
direct sunlight and excess heat or cold.
2. For long storage, it is recommended to store a fully charged
battery pack in a cool dry place out of the charger for optimal
results.
NOTE: Battery packs should not be stored completely depleted of
charge. The battery pack will need to be recharged before use.
SAVE THESE INSTRUCTIONS
FOR FUTURE USE
Introduction
The DCB090 USB power source is equipped with two USB
Type A charging ports and is designed to charge or supply power to
USB compatible devices with the use of D
EWALT 12V Max* and 20V
Max* lithium ion battery packs. Consult the chart at the end of this
manual for compatibility of chargers and battery packs.
A
D
B
C
FIG. 2
COMPONENTS (Fig. 2)
WARNING: Never modify the DCB090 USB power source or any
part of it. Damage or personal injury could result.
A. Battery pack
B. Power Source
C. USB charging port
D. Fuel gauge
OPERATION
Installing and Removing the Battery Pack
(Fig. 2)
NOTE: For best results, make sure your battery pack is fully charged.
IMPORTANT: To avoid battery charge depletion, remove the battery
pack from the DCB090 USB power source when not in use.
TO INSTALL BATTERY PACK
Slide the battery pack (A) into the DCB090 USB power source (B) until
the battery pack is firmly seated.
WARNING: Fire hazard. Do not store or carry the battery
pack so that metal objects can contact exposed battery
terminals.
TO REMOVE THE BATTERY PACK
Grasp battery pack firmly and pull from the DCB090 USB power
source. Insert battery into the charger as described in the charger
section of this manual.
FUEL GAUGE
When the battery is inserted into the DCB090 USB power source, the
LED will flash briefly, then the number of lights will illuminate for ten
seconds based on the state of charge of the battery pack.
English
7
