DeWalt DCB107 User Manual

12
ENGLISH
Spray Wand Nozzles (Fig.B,H)
The nozzles for the spray wand are stored in the nozzle holder
2
on the panel assembly
1
. Colours on the panel identify nozzle
location and spray pattern. Refer to the following chart to
choose the correct nozzle for the job to beperformed.
Nozzle
Colour
Spray Pattern Uses Surfaces***
Red
0˚
powerful pinpoint
for very intense
cleaning
metal or concrete;
DO NOT use on
wood
Yellow
15˚
intense cleaning of
small areas
metal, concrete or
wood
Green
25
˚
intense cleaning of
larger areas
metal, concrete or
wood
White
40
˚
covers wide areas of
cleaning
metal, concrete,
wood or vinyl
Black
low pressure
applies chemical/
cleaning soaps
metal, concrete,
wood or vinyl
*** NOTICE: The high pressure spray from your pressure washer
is capable of causing damage to surfaces such as wood,
glass, automobile paint, auto striping and trim, delicate
objects such as flowers and shrubs. Before spraying, check
the item to be cleaned to assure yourself that it is strong
enough to resist damage from the force ofspray.
Changing Nozzles on Spray Wand (Fig.H)

DANGER: Risk of fluid injection. Do not direct discharge
stream toward persons, unprotected skin, eyes or any pets
or animals. Serious injury willoccur.

WARNING: Flying objects could cause risk of serious
injury. DO NOT attempt to change nozzles while
pressure washer is running. Turn engine off before
changingnozzles.
1. Pull quick-connect coupler back and insertnozzle.
2. Release quick-connect coupler and twist nozzle to make
sure it is secure incoupler.

WARNING: Flying objects could cause risk of serious
injury. Ensure nozzle is completely inserted in quick-
connect socket and quick- connect collar is fully engaged
(forward) before squeezing spray guntrigger.
Fig. H
Chemicals/Cleaning Soaps
Applying chemicals or cleaning soaps is a low
pressureoperation.
NOTE: Use only chemical and cleaning soaps designed for
pressure washer use. Do not usebleach.
To Apply Chemical/Cleaning Soaps (Fig.I)
1. Press chemical/soap hose
26
onto barbed fitting located
near high pressure hose connection of pump asshown.
Fig. I
26
2. Place the other end of chemical/soap hose with filter
into the container holding the chemical/cleaning soap.
NOTE:For every 10 gallons (38 liters) of water pumped 1
gallon (3.8 liters) of chemical/cleaning soap will beused.
3. Install low-pressure (black) nozzle into quick connect
fitting of spray wand, refer to Spray Wand Nozzles.
NOTE:Chemical/cleaning soaps will not siphon if the black
soap nozzle is not installed on the spraywand.
4. After use of chemical/cleaning soaps, place chemical/
soap hose into container of clean water and draw
clean water through chemical injection system to rinse
systemthoroughly.
NOTICE: Risk of property damage. Failure to do so
could cause damage to the pump. Pumps damaged
due to chemical/cleaning soaps will not be covered
underwarranty.
Starting

WARNING: To reduce the risk of injury, read the pressure
washer instruction manual and the engine instruction
manual before starting pressurewasher.

DANGER: Risk of fluid injection and laceration. When
using the high pressure setting, DO NOT allow the high
pressure spray to come in contact with unprotected skin,
eyes, or with any pets, animals, or people. Serious injury
willoccur.

DeWalt DCB107 Specifications

General

Battery Chemistry	Lithium-Ion
Charging Ports	1
Output Voltage	20V
Charging Time	1 hour
Indicator	LED
Voltage	20V
Compatible Battery Series	20V MAX
Input Voltage	120V
