Tool Connect™ Chip (Fig.R)
WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Your tool is Tool Connect™ Chip ready and has a location for
installation of a Tool Connect™ Chip.
Tool Connect™ Chip is an optional application for your smart
device (such as a smart phone or tablet) that connects
the device to utilize the mobile application for inventory
management functions.
Refer to Tool Connect™ Chip Instruction Sheet for
moreinformation.
Installing the Tool Connect™ Chip
1. Remove the retaining screws
32
that hold the Tool
Connect™ Chip protective cover
31
into thetool.
2. Remove the protective cover and insert the Tool
Connect™ Chip into the empty pocket
30
.
3. Ensure that the Tool Connect™ Chip is flush with the
housing. Secure it with the retaining screws and tighten
thescrews.
4. Refer to Tool Connect™ Chip Instruction Sheet for
furtherinstructions.
It is recommended that a saw chain be sharpened no more
than fourtimes.
NOTE: The cutters will dull immediately if they touch the
ground/dirt or a nail whilecutting.
To get the best possible performance from your chainsaw it
is important to keep the teeth of the saw chain sharp. Follow
these helpful tips for proper saw chain sharpening:
1. For best results use a 5/32" (4 mm) file and a file holder
or filing guide to sharpen your saw chain. This will ensure
you always get the correct sharpeningangles.
2. Place the file holder flat on the top plate and depth
gauge of thecutter.
3. Keep the correct top plate
33
filing angle line of 30° on
your file guide parallel with your chain (file at 60° from
chain viewed from the side) as shownin Fig. T.
4. Sharpen cutters on one side of the chain first. File from
the inside of each cutter to the outside. Then turn your
saw around and repeat the processes (2, 3, 4) for cutters
on the other side of thechain.
NOTE: Use a flat file to file the tops of the rakers (portion
of chain link in front of the cutter) so they are about .025"
(.635 mm) below the tips of the cutters as shownin Fig. S.
5. Keep all cutter lengthsequal as shownin Fig. U.
6. If damage is present on the chrome surface of the
top plates or side plates, file back until such damage
isremoved.
CAUTION: After filing, the cutter will be sharp, use
extra caution during thisprocess.
Saw Chain Sharpening (Fig.S–U)
CAUTION: Sharp chain. Always wear protective gloves
when handling the chain. The chain is sharp and can
cut you when it is notrunning.
WARNING: Sharp moving chain. To prevent accidental
operation, ensure that battery is removed from the tool
before performing the following operations. Failure to
do this could result in serious personalinjury.
WARNING: Do not over file chain rakers, this will
increase the risk of kickback. If the chain has been
sharpened more than four times, replaceit.
Each time the chain is sharpened, it loses some of the low
kickback qualities and extra caution should beused.
Accessories
WARNING:
Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this product could be hazardous.
To reduce the risk of injury, only
DeWALT recommended
accessories should be used with thisproduct.
Recommended accessories for use with your product are
available at extra cost from your local dealer or authorized
service center. If you need assistance in locating any
accessory, please contact
DeWALT. Call 1-800-4-DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
WARNING: Sharp moving chain. To prevent accidental
operation, ensure the battery is removed from the tool
before performing the following operations. Failure to
do this could result in serious personalinjury.
Replacement sprockets are available from your nearest
authorized servicecenter:
DeWALT part number,
NA265339.
NOTE: The sprocket bolt
34
is left-hand thread.
1. Engage the chain brake. Push the chain brake/front hand
guard
10
forward until it clicks intoplace.
2. Remove sprocket cover
13
as described in Installing the
Guide Bar and Saw Chainsection.
3. Remove saw chain
12
and guide bar
11
as described in
Replacing the Saw Chainsection.
4. Hold the sprocket
27
in place with a pair of adjustable
pliers (not included).
5. With a 10 mm wrench (not included) rotate the left‑
hand thread sprocket bolt
34
clockwise and remove it.
6. Lift the sprocket
27
off of the D‑shaped shaft
35
.
7. Clean the sprocket
27
of any debris or replace it with a
new sprocket
27
.
8. Install the sprocket
27
. Align the D‑slot
36
on the
sprocket
27
the D‑shaped shaft
35
.
9. Hold the sprocket
27
in place with a pair of adjustable
pliers. Use a 10 mm wrench (not included) to rotate the
left‑hand thread sprocket bolt
34
counterclockwise.
10. Using a torque wrench,
tighten the sprocket bolt
34
to6ft.lbs (8N.m).
11. Follow instructions for Installing the Guide Bar and
SawChain.
