DeWalt DCD7781 User Manual

11
ENGLISH
remove drill bit from work, and determine cause of stalling.
DO NOT CLICK TRIGGER ON AND OFF IN AN ATTEMPT
TO START A STALLED DRILL — THIS CAN DAMAGE
THEDRILL.
7. To minimize stalling or breaking through the material,
reduce pressure on drill and ease the bit through the last
fractional part of thehole.
8. Keep the motor running when pulling the bit back out of a
drilled hole. This will help preventjamming.
9. With variable speed drills there is no need to center punch
the point to be drilled. Use a slow speed to start the hole
and accelerate by squeezing the trigger harder when the
hole is deep enough to drill without the bit skippingout.
Hammerdrill Operation (Fig.F)
DCD7781 Only
1. Turn the collar
3
to the hammerdrillsymbol.
2. Select the high speed setting by sliding the selector back
(away from the chuck).
IMPORTANT: Use carbide-tipped or masonry bitsonly.
3. Drill with just enough force on the hammer to keep it from
bouncing excessively or “rising” off the bit. Too much force
will cause slower drilling speeds, overheating and lower
drillingrate.
4. Drill straight, keeping the bit at a right angle to the work. Do
not exert side pressure on the bit when drillling as this will
cause clogging of the bit flutes and a slower drillingspeed.
5. When drilling deep holes, if the hammer speed starts to
drop off, pull the bit partially out of the hole with tool stil
running to help clear debris from thehole.
NOTE: A smooth, even flow of dust from the hole indicates
proper drillingrate.
MAINTENANCE
Your DeWALT power tool has been designed to operate
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regularcleaning.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments/accessories or when making
repairs. An accidental start-up can causeinjury.
The charger and battery pack are notserviceable.
Lubrication
Your power tool requires no additionallubrication.
Cleaning

WARNING: Blow dirt and dust out of the main housing
with dry air as often as dirt is seen collecting in and around
the air vents. Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the tool. These
chemicals may weaken the materials used in these parts.
Use a cloth dampened only with water and mild soap.
Never let any liquid get inside the tool; never immerse any
part of the tool into aliquid.
Optional Accessories

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
Protecting the Environment
Separate collection. Products and batteries marked
with this symbol must not be disposed of with normal
householdwaste.
Products and batteries contain materials that can
be recovered or recycled reducing the demand for raw
materials. Please recycle electrical products and batteries
according to local provisions. Further information is available at
www.2helpU.com.
Rechargeable Battery Pack
This long life battery pack must be recharged when it fails
to produce sufficient power on jobs which were easily done
before. At the end of its technical life, discard it with due care for
our environment:
• Run the battery pack down completely, then remove it from
thetool.
• Li-Ion cells are recyclable. Take them to your dealer or a
local recycling station. The collected battery packs will be
recycled or disposed ofproperly.
After Service and Repair
DEWALT service centers are staffed with trained personnel to
provide customers with efficient and reliable product service.
We do not take any responsibility when you have repaired
in unauthorized service center. You can refer to the leaflet of
CONTACT CENTER LOCATOR in product package and contact
us through hotline, website or social media to find the nearest
DEWALT service center around you.

DeWalt DCD7781 Specifications

General

Type	Cordless Drill
Voltage	20V
Max Torque	300 UWO
Speed Settings	2
Weight	3.6 lbs
Battery Type	Lithium-Ion (Li-Ion)
Chuck Size	1/2 inch
