DeWalt DCED400 - Assembly and Adjustments; Pole Assembly and Handle Attachment; Cut Depth and Edge Guide Adjustment

ENGLISH
10
Pull-Up Edge Guide (Fig. I, J)
The edge guide is useful for cutting a straight path along
sidewalks. For landscaping or trenching in the yard the edge
guide can interfere with moving the edger through hard soil
or sod. The edge guide
16
can be adjusted so that the edger
will also perform trenching or landscapingoperations.
To Change Position of the Edge Guide
• To use without the edge guide, pull edge guide knob
15
away from the housing and slide the edge guide knob to
the upper guide notch
26
on the housing.
NOTE: In this position the edge guide is raised and the
blade can more easily trench or cut along the edges
Cut Depth Adjustment (Fig.H)

WARNING: NEVER OPERATE
APPLIANCE WITHOUT GUARD FIRMLY IN PLACE.
The guard must always be properly attached on the
appliance to protect theuser.

WARNING: Do not use edger if the small
guard
23
does not move when adjusting depth. Ensure
the small guard is located toward the bottom of the
depth adjustment wheel
13
. Do not operate edger if
the small guard is not inplace.
The depth of cut can be adjusted to allow a deeper or
shallower cut, and to increase the life of the blade. There
are three adjustible settings that can be set using the depth
adjustment lever
14
.
1. Wait for blade to come to completestop.
2. Remove the batteryfrom thetool.
3. For a shallower cut, pull the depth adjustment lever away
from the housing and slide it down into one of the lower
depth adjustment slots
24
on thehousing.
4. For a deeper cut, pull the depth adjustment lever away
from the housing and slide it upwards into one of the
upper depth adjustment slots
25
on thehousing.
NOTE: Recommend 1.4" (3.5 cm) depth foredging.
5. Ensure the depth adjustment lever is fully seated in one
of the depth adjustment slots before using thetool.
NOTE: Thick overgrowth may drag on the guard. Reduce cut
depth to minimum to help reduce thiseffect.

WARNING: Never remove the guard.
Damage or personal injury couldresult.

WARNING: NEVER OPERATE
APPLIANCE WITHOUT GUARD FIRMLY IN PLACE.
The guard must always be properly attached on the
appliance to protect theuser.
The auxiliary handle
4
is positioned to maximize balance.
However, if adjustment is necessary, loosen the four bolts
22
with a hex wrench and slide the auxiliary handle up or down
the upper pole.
Attaching the Auxiliary Handle (Fig.F)
1. Place the auxiliary handle
4
on top of the handle base
21
so the upper pole
5
is betweenthem.
2. Hold the auxiliary handle in place and slide the handle
bolts
22
into the handle from the top, threading them
into the handlebase.
3. Tighten the handle bolts with the supplied hex
wrench
20
. Ensure the handle is securelyattached.
Adjustment (Fig. G)

WARNING: To reduce the risk of serious
personal injury, turn appliance off and remove
battery before making any adjustments or
removing/installing attachments oraccessories.
Assembling the Pole FIG. D, E
1. To assemble the pole, line up the upper pole
5
and the
lower pole
6
as shown in Fig. D. Press down the latching
button
17
and slide the upper pole into the lower pole.
Avoid pinching the wire. Ensure the latching button
engages the latch hole
18
.
2. Secure the poles by tightening the middle bolt
19
with
the supplied hex wrench
20
as shown in Fig.E.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious
personal injury, turn unit off and remove the
battery pack before making any adjustments or
removing/installing attachments or accessories.
An accidental start‑up can causeinjury.
Wall Mounting
Some DEWALT chargers are designed to be wall mountable
or to sit upright on a table or work surface. If wall mounting,
locate the charger within reach of an electrical outlet, and
away from a corner or other obstructions which may impede
air flow. Use the back of the charger as a template for the
location of the mounting screws on the wall. Mount the
charger securely using drywall screws (purchased separately)
at least 1” (25.4mm) long, with a screw head diameter of
0.28–0.35” (7–9mm), screwed into wood to an optimal
depth leaving approximately 7/32” (5.5 mm) of the screw
exposed. Align the slots on the back of the charger with the
exposed screws and fully engage them in theslots.
SAVE THESE INSTRUCTIONS FOR
FUTURE USE
Charger Cleaning Instructions

WARNING:Shock hazard. Disconnectthe
charger from the AC outlet before cleaning. Dirt and
grease may be removed from the exterior of the charger
using a cloth or soft non‑metallic brush. Do not use
water or any cleaningsolutions.
