ASSEMBLY AND ADJUSTMENTS

DANGER: To reduce the risk of serious personal
injury, turn unit off and remove the safety key and
battery packs before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.
Description (Fig. A)

WARNING: Never modify the power tool or any part of it.
Damage or personal injury couldresult.
1
ON‑OFF switch box
2
ON‑OFF button
3
Safety key
4
Main handle (upper handle)
5
Bail handle
6
Self drive bail handle
7
Handle locks
8
Handle brackets
9
Handle storage detent holes
10
Battery port cover
11
Cut height adjust lever
12
Rear door cover
13
Grass collection bag
14
Grass collection bag handle
15
Side flap
16
Side discharge chute
17
Lower handle
18
Upper handle knobs
Intended Use
This lawn mower has been designed for professional lawn
mowingapplications.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
This lawn mower is a professional lawn care appliance.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators use
thistool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
Date Code Position (Fig.A)
The date code
19
, which also includes the year of manufacture,
is printed into thehousing.
Example:
2021XX XX
Year and Week of Manufacture
Markings on Tool
The following pictograms are shown on the tool:
L
Read instruction manual beforeuse.
Beware of sharp blades. Blades continue to rotate after
the motor is switched off. Remove disabling device
beforemaintenance.
Beware of flying objects. Keep bystanders away from
the cuttingarea.
98
Directive 2000/14/EC guaranteed soundpower.
Do not expose torain.
The blades will continue to rotate after the
machine is switchedoff.
Package Contents
The package contains:
1 Lawn mower
1 Grass Collection Bag
1 Side Discharge Chute
1 Safety Key
1 Instruction manual
NOTE: Battery packs, chargers and kitboxes are not included
with N models. Battery packs and chargers are not included with
NT models. Bmodels include Bluetooth® batterypacks.
NOTE: The Bluetooth® word mark and logos are registered
trademarks owned by the Bluetooth®, SIG, Inc. and any use of
such marks by DeWALT is under license. Other trademarks and
trade names are those of their respectiveowners.
• Check for damage to the tool, parts or accessories which may
have occurred duringtransport.
• Take the time to thoroughly read and understand this manual
prior tooperation.
Battery Type
The following tools operate on a 18 volt battery pack:
DCMWSP564 , Cat #3.
These battery packs may be used: DCB181, DCB182, DCB183,
DCB183B, DCB183G, DCB184, DCB184B, DCB184G, DCB185,
DCB187, DCB189, DCB546, DCB547, DCB548. Refer to Technical
Data for moreinformation.
B
USE (without transport cap). Example: Wh rating
indicates 108Wh (1battery with 108Wh).
A
TRANSPORT (with built‑in transport cap). Example: Wh
rating indicates 3x 36Wh (3batteries of 36Wh).
