DeWalt DCR019 - Assembly and Adjustments; AC Operation; Battery Pack Installation; Coin Cell Battery Installation

8
ENGLISH
9
Battery pack
10
Fuel gauge button
11
Battery release button
12
Auxiliary port
13
Battery door screw
14
Coin cell battery
15
Coin cell battery door
Intended Use
This radio is designed for professional use.
DO NOT use under wet conditions or in the presence of
flammable liquids orgases.
DO NOT let children come into contact with the unit.
Supervision is required when inexperienced operators use
thisunit.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
withoutsupervision.
• This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with thisproduct.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and disconnect from power
source and/or remove battery pack before cleaning,
making any adjustments or removing/installing
attachments or accessories.
AC Operation
Unwrap power cord and plug into 230V AC wall outlet.
Inserting and Removing the Battery Pack
(Fig. D)
NOTE: Make sure your battery pack
9
is fullycharged.
To Install the Battery Pack
1. Align the battery pack
9
with the rails inside the
batteryport.
2. Slide it in until the battery pack is firmly seated and ensure
that you hear the lock snap intoplace. Be sure that it does
notdisengage.
To Remove the Battery Pack
1. Press the battery release button
11
and firmly pull the
battery pack out of the batteryport.
2. Insert battery pack into the charger as described in the
charger section of thismanual.
Fuel Gauge Battery Packs (Fig. D)
Some
DeWALT
battery packs include a fuel gauge which
consists of three green LED lights that indicate the level of
charge remaining in the batterypack.
To actuate the fuel gauge
10
, press and hold the fuel gauge
button. A combination of the three green LED lights will
illuminate designating the level of charge left. When the level
of charge in the battery is below the usable limit, the fuel gauge
will not illuminate and the battery will need to berecharged.
NOTE: The fuel gauge is only an indication of the charge left on
the battery pack. It does not indicate tool functionality and is
subject to variation based on product components, temperature
and end-userapplication.
To Install the Coin Cell Battery (Fig. B)

WARNING: When replacing battery, replace it with the
same brand and type. Observe correct polarity (+ and –)
when replacing batteries. Do not store or carry batteries so
that metal objects can contact exposed battery terminals.
Your radio is equipped with memory capacity in order to store
the time and your selected memory channels. When the radio is
OFF, this memory capacity is powered by one coin cell battery
that is included with the radio.
1. Turn the radio off and unplug from the power source.
2. Unscrew the screw
13
on the battery door
15
.
3. Press down on the battery door latch and pull to open.
4. Install the coin cell battery
14
according to the diagram
inside the coin cell battery area.
5. Replace the battery door, insert screw and tighten.
NOTE: To reset the LCD display, clock and presets, remove the
coin cell battery and re-install it. Follow this procedure if the
screen seems to lock in place.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn unit off and disconnect from power
source and/or remove battery pack before cleaning,
making any adjustments or removing/installing
attachments or accessories.
Operating the Radio (Fig. A, C)
Power/Volume Adjustment
1. To turn the radio on, press the power button
1
.
2. Turn the dial
2
clockwise to increase the volume. To
decrease the volume, turn anticlockwise.
Mode Function
To choose one of the mode functions (FM, AM, or AUX), push
the mode button
4
until the desired function is found. For
example, if the radio is on FM, seen in upper left portion of LCD
display
8
, push the mode button twice to change to AM.
Tune or Seek Function
There are two methods for finding the desired frequency.
To Tune: Push the right arrow to move the tuner up the
frequency band. Push the left arrow to move the tuner down
the frequency band.
To Seek: Press the right arrow button
3
once and release.
The tuner frequency will increase to seek the first radio station
