DeWalt DCS7485 Instruction Manual

1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or propertydamage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety relatedmessage.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and
allinstructions. Failure to follow the warnings
and instructions may result in electric shock, fire
and/or seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
1
Table
2
Blade
3
Rip scale indicator
4
Fine adjust knob
5
Rail lock lever
6
Blade height adjustment wheel
7
Bevel lock lever
8
ON/OFF assembly
9
Mounting holes
10
Miter gauge
11
Blade guard assembly
12
Battery
13
Battery release button
14
Anti-kickback assembly
15
Dust collection port
16
Guard dust collection port
17
Throat plate
18
Rip fence
19
Rip fence latch
20
Narrow ripping fence/support extension
21
Blade wrenches (stored position)
22
Push stick (stored position)
23
Riving knife (non thru sawing) (Fig.G)
24
Carry handle
25
Miter gauge track
Fig. A
2
16
11
1
14
21
25
24
9
15
3
10
8
11
17
9
7
5
22
20
18
19
4
6
13
12
