Instructions for Use
WARNING:
• This detector should only be used to detect a Class 2 laser.
• Always observe the safety instructions and applicable regulations for this detector
and for the laser.
• Before first use, remove and discard the protective tape from the screens.
Detector Operation (Fig. 1)
1. Set up and position the laser.
2. Turn the detector on by pressing the power button (E).
3. Position the detector so that the sensor window (I) is facing the laser beam. Move the
detector up or down within the approximate area of the beam, until you have centered
the detector. For information about the display window indicators and the audible signal
indicators, refer to the table titled Indicators.
INDICATORS
Above
Grade
Slightly
Above
Grade
On
Grade
Slightly
Below
Grade
Below
Grade
audible
signals
fast
beep
fast
beep
steady
tone
slow
beep
slow
beep
display
icons
4. Use the marking notches (D) to accurately mark the position of the laser beam.
Mounting on a Grade Rod (Fig. 1, 2)
1. To secure your detector to a grade rod, first attach the detector to the clamp by pushing in
on the clamp latch (J). Slide the tracks (K) on the clamp around the rail (L) on the detector
until the latch (M) on the clamp pops into the latch hole (N) on the detector.
2. Open the jaws of the clamp by turning the clamp knob (O) counterclockwise.
3. Position the detector at the height needed and turn the clamp knob clockwise to secure the
clamp on the rod.
4. To make adjustments in height, slightly loosen the clamp, reposition and retighten.
MAINTENANCE
WARNING: To reduce the risk of injury, turn unit off and disconnect it from power
source before installing and removing accessories, before adjusting or when making
repairs. An accidental start-up can cause injury.
Your attachment has been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper tool care and regular
cleaning.
Detector Service
Except for batteries, there are no user serviceable parts in the Digital Laser Detector. Do not
disassemble the unit. Unauthorised tampering with the laser detector will void all warranties.
Detector Cleaning and Storage
• Dirt and grease may be removed from the exterior of the detector using a cloth or soft,
non-metallic brush.
• The DEWALT digital laser detector is rain resistant but not immersible. Do not pour water on
the unit or submerge it under water.
• The best storage place is one that is cool and dry—away from direct sunlight and excess
heat or cold.
Detector Troubleshooting
THE DETECTOR WILL NOT TURN ON
• Press and release the power button.
• Check to see that the battery is in place and in the proper position.
• If the detector is very cold, allow it to warm up in a heated area.
• Replace the 9-volt battery. Turn the unit on.
• If the detector still does not turn on, take the detector to a DeWALT service center.
THE DETECTOR’S SPEAKER MAKES NO SOUND
• Ensure that the detector is on.
• Press the volume button. It will toggle on and off.
• Ensure that the laser is turned on and that it is emitting a laser beam.
• If the detector is still not making any sound, take it to a DEWALT service center.
THE DETECTOR DOES NOT RESPOND TO THE BEAM FROM ANOTHER LASER
UNIT
• The DeWALT Digital Laser Detector has been designed to work only with the DW088,
DW089, DW0811, DW0822, DW0851 (Line) DW088LR/LG; DW089LR/LG; DW0811LR/LG
and certain other compatible line lasers.
THE DETECTOR GIVES OFF A TONE BUT THE LCD DISPLAY WINDOW DOES NOT
FUNCTION
• If the detector is very cold, allow it to warm up in a heated area.
• If the LCD display window is still not functioning, take the detector to a DeWALT service
center.
BRIGHT LIGHT SHINING ON DETECTOR CAUSES CONTINUOUS “ON-GRADE”
SIGNAL
• In the presence of very intense ambient light, the detector may give a false or erratic
indication of level.
• Reposition the detector out of the intense light or shade the sensor window (I) to resume
normal operation.
Accessories
WARNING: Since accessories, other than those offered by DeWALT, have not been tested
with this product, use of such accessories with this tool could be hazardous. To reduce the risk
of injury, only DeWALT recommended accessories should be used with this product.
Recommended accessories for use with your tool are available at extra cost from your local dealer
or authorized service center. If you need assistance in locating any accessory, please contact
DeWALT Industrial Tool Co., 701 East Joppa Road, Towson, MD 21286, call 1-800-4-DeWALT
(1-800-433-9258) or visit our website: www.dewalt.com.
Repairs
To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment (including
brush inspection and replacement) should be performed by a DeWALT factory service center,
a DeWALT authorized service center or other qualified service personnel. Always use identical
replacement parts.
Register Online
Thank you for your purchase. Register your product now for:
• WARRANTY SERVICE: Registering your product will help you obtain more efficient
warranty service in case there is a problem with your product.
• CONFIRMATION OF OWNERSHIP: In case of an insurance loss, such as fire, flood or
theft, your registration of ownership will serve as your proof of purchase.
• FOR YOUR SAFETY: Registering your product will allow us to contact you in the unlikely
event a safety notification is required under the Federal Consumer Safety Act.
Register online at www.dewalt.com/register.
