Description (fi g. 1)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
a. Axle
b. Wheels
c. Handle-side leg release levers
d. Wheel-side leg release levers
e. Locking pins
f. Legs
g. Handle
h. Handle feet
i. Kickstand
j. Saw mounting holes
INTENDED USE
This rolling table saw stand is designed for use with
D
EWALT DWE7491 table saw. It may also be used
with DW745 table saw when mounted with included
adapter brackets and hardware. If you have any
problem with alignment or mounting, consult an
authorised DEWALT repair agent.
DO NOT use under wet conditions or in the
presence of flammable liquids or gases.
DO NOT let children come into contact with the
tool. Supervision is required when inexperienced
operators use this tool.
This product is not intended for use by persons
(including children) suffering from diminished
physical, sensory or mental abilities; lack of
experience, knowledge or skills unless they are
supervised by a person responsible for their
safety. Children should never be left alone with
this product.
ASSEMBLY
Assembling Stand Frame Halves
(fi g. 2)
1. Slide smaller tube diameter into opposite tube
side as shown until holes align.
2. Install M6x12 pan head bolts until tight on both
sides.
Attaching the Wheels and Axle
(fi g. 3, 4)
1. Attach the axle (a) to the end bracket (k) by
aligning the pre-drilled holes. Secure axle to end
bracket using two carriage bolts, washers and
lock nuts provided.
DO NOT modify or use stand for
operations for which it is unintended.
DO NOT use the stand on uneven
surfaces. DO NOT use the stand with
the legs folded and stand sitting on the
ground. The stand is designed to be
used on a flat, stable surface.
Package Contents
The package contains:
1 stand, right side
1 stand, left side
2 wheels
1 rear axle
1 kickstand assembly
2 tube plugs
1 handle assembly
2 handle feet
2 carriage head bolts
2 x M6 pan head bolts
8 x M8 hex head bolts
12 M8 lock nuts
2 Flat washers
1 Hex key wrench
1 Open end wrench
DWE7491 saw mounting hardware:
4 M8x75 pan head bolts
4 M8 lock nuts
DW745 saw mounting hardware:
2 adapter brackets
4 M6 pan head bolts
4 M6 Flat washers
4 M6 Lock nuts
4 M8 pan head bolts
4 M8 Flat washers
4 M8 Lock nuts
1 Instruction manual
Check for damage to the tool, parts or
accessories which may have occurred
during transport.
Take the time to thoroughly read and
understand this manual prior to operation.
