CROSS CUT MITRE SAW
DWS773, DWS774
TECHNICAL DATA
DWS773 DWS774
Voltage:
Europe V 230 230
U.K. & Ireland V 230/115 230/115
Fuses:
Europe
230 V
A
10
(mains)
10
(mains)
U.K. & Ireland
230 V
A
13
(in plugs)
13
(in plugs)
U.K. & Ireland
115 V
A
16
(mains)
16
(mains)
Type 1 1
Power input W 1300 1400
Blade diameter mm 216 216
Blade bore mm 30 30
Blade speed, max. min
-1
4600/4500 4600/4500
Mitre positions, max.
left
right
48°
48°
48°
48°
Bevel position, max. left 48° 48°
Compound mitre
bevel
mitre
45°
45°
45°
45°
Capacities:
cross-cut 90° (max height) mm 70 x 20 70 x 20
cross-cut 90° mm 60 x 250 60 x 250
mitre 45° mm 60 x 170 60 x 170
mitre 48° mm 60 x 160 60 x 160
bevel 45° mm 48 x 250 48 x 250
bevel 48° mm 45 x 250 45 x 250
Overall dimensions(with table extensions) mm 625 x 425 x 355 625 x 425 x 355
Dimensions(without table extensions) mm 445 x 425 x 355 445 x 425 x 355
XPS No Yes
Weight kg 11.5 11.5
Noise values and/or vibration values (triax vector sum) according to EN62841:
L
PA
(sound pressure) dB(A) 92 92
L
WA
(acoustic power) dB(A) 98 98
K (acoustic power uncertainty) dB(A) 0,3 0,3
The vibration and/or noise emission level given in this information sheet
has been measured in accordance with a standardised test given in
EN62841 and may be used to compare one tool with another. It may be
used for a preliminary assessment ofexposure.

WARNING: The declared vibration and/or noise emission level
represents the main applications of the tool. However if the tool
is used for different applications, with different accessories or
poorly maintained, the vibration and/or noise emission may differ.
This may significantly increase the exposure level over the total
workingperiod.
An estimation of the level of exposure to vibration and/or noise
should also take into account the times when the tool is switched
off or when it is running but not actually doing the job. This may
significantly reduce the exposure level over the total workingperiod.
Identify additional safety measures to protect the operator from
the effects of vibration and/or noise such as: maintain the tool
and the accessories, keep the hands warm (relevant for vibration),
organisation of workpatterns.
Electrical Power Source
This device is intended for the connection to a power supply system
with maximum permissible system impedance Zmax of 0,39 Ohm at the
interface point (power service box) of user’ssupply.
The user has to ensure that this device is connected only to a power
system which fulfils the requirement above. If necessary, the user can
ask the public power supply company for the system impedance at the
interfacepoint.
EC-Declaration of Conformity
In accordance with
Machinery Directive 2006/42/EC
Product: Cross-cut Mitre Saw
Types: DWS773, DWS774
DEWALT declares that these products described under Technical Data
are in compliance with the harmonized standards: EN62841-1:2015
and EN62841-3-9:2015 + A11:2017. These products also comply with
Directive 2014/30/EU and 2011/65/EC.
For more information, please contact DEWALT at the following address or
refer to the back of themanual.
The undersigned is responsible for compilation of the technical file and
makes this declaration on behalf ofDEWALT.
Markus Rompel
Vice President of Engineering, PTE-Europe
DeWALT
, Richard-Klinger-Straße 11,
D-65510, Idstein, Germany
02.09.2019
GENERAL SAFETY NOTES
Read the safety manual carefully before use in order to
ensure asafe and proper operation of the device. Retain
the instruction manual until the product is disposedof.
Intended Use
The Cross-Cut Mitre Saw has to be used in accordance with the
specifications of this safety manual and the operational manual. Mitre Saws
are not “toys” and require prudent, responsible and carefulhandling.
The Mitre Saw has been designed for professional cutting wood, wood
products and plastics. It performs the sawing operations of cross-cutting,
bevelling and mitring easily, accurately andsafety.
The Mitre Saw is designed for use with a nominal blade diameter
216mm carbide tipblade.
Responsibilities of the employer, for example:
• Complying with the deadlines for periodic inspections as well as
ordering repair measures to be performed by by an authorized
DeWALT
repairagent.
• Safe storage of the Mitre Saw out of reach ofchildren.
• Provisioning and ensuring the usage of protective equipment, see
chapter 1.3 “Personal Protective Equipment”.
The Mitre Saw may only be used by persons over 18 years of age or
apprentices/trainees over 16 years of age (while in the presence of
