Components (Fig. 2)
A. Positive (+) Red Clamp with
Clamp Connector
B. Negative (–) Black Clamp
with Clamp Connector
C. Handle
D. Control Panel (see Fig. 1)
E. Clamp Storage Pouch
F. Air Hose and SureFit
®
Nozzle in Storage Pouch
G. USB Power/Fault Indicators
H. USB Ports
I. Dual 120 Volt AC Outlets
J. Clamps (A and B) shown
with Clamp Connector (P)
C
D
E
A
B
F
H
G
I
J
K. 12V DC Charging Port
(under protective cover)
L. Built-in 120 Volt AC Charger
(under protective cover)
M. LED Area Light (two banks
of three LEDs)
N. 12 Volt DC Charging
Adapter
O. Clamp Connection Slot
P. Clamp Connector (for
connecting the battery
clamps to the Clamp
Connection Slot)
M M
O
P
N
K
L
