DXST10000
PARTS LIST
No. Description
1 Vertical Beam
2 Pre-Bolted Vertical Assembly
3 Vertical Assembly Bolt
4 Crossbeam
5 Shelf Support Strap
6 Safety Strap With Weld Nut
7 Safety Strap Bolt
8 Wire Grid
9 Laminate Deck
No. Description
10 Locking Shelf Pin
11 Locking Grid Clip
12 Carriage Bolt
13 10 mm Nut
14 10 mm Wrench
15 4 mm Hex Key
16 4 mm Hex Bit
17 Wall Mount Bracket Assembly
3
BEFORE YOU BEGIN:
Read all instructions thoroughly.
Remove all components from the box, and lay them on the floor
in an orderly fashion.
Keep this information for further reference.
